TH-F
TH Laser
8456110090
Products Feature
1.Accurate laser cleaning for exact position and precise size.
2.Widely applied in flat,curved and three-dimensional surface for work piece of elastic material and plastic with very small and deep holes.
3.Flexible operation for work pieces with complicated geometric construction can be realized by mechanized or hand-held laser cleaning head.
4.No maintenance and no consumables,dust-free,no chemicals,no pollution.
5.Non-contact cleaning and no damage for substrate Extremely.
6. Low cleaning cost and High cleaning efficiency.
Technical Parameter
Model | TH-F |
Laser Generator | Raycus |
Laser Power | 100W-2000W |
Machine Weight | 180KG |
Laser Gun Weight | 1.8KG |
Power Consumption | 2000W |
Cooling System | Forced-Air Cooling |
Working Mode | Manual Or Auto |
Machine Life Span | 50000 Hours |
Cable Length | 3 Mtrs (Can Be Lengthened) |
Working Distance | 150mm / 2500mm / 500mm |
Laser Wavelength | 1064 um |
Power Supply | 220v/50hz/2A Or380v/50HZ/2A |
Work Temperature | 5℃ - 45 ℃ |
Work Humidity | < 90% |
Laser Class | IV |
Application
1.The surface on metallic,plastic,ceramics,glass,stone or concrete:
2.Metal surface derusting
3.Surface paint removal paint treatment
4.Surface without dirt,stains,dirt cleaning
5.Surface coating,coating removal
6.Oxide surface,Oil stain and contaminant cleaning
7.Welding surface / spray surface per-treatment
8.Stone figure surface dust & attachment cleaning.
9.Rubber/plastic/metal mold residue cleaning
Sample
