TH-M
TH Laser
8456110090
Advantages
1.Lathe bed use all-welded structure,strong reasonable,simple operation,and durable.
2.Powerful stepper motor driver,imported linear guide rails,running smoothly,high accuracy,long time service.
3.Gear wheel/rack transmission,high precision,could engrave 1mm letter clearly.
4.Air cooling spindle/(Italy HSD Spindle optional)apply to long time processing of wood products.
5.The advanced professional control system compatible with many instruction format,may achieve process function in interruption of power supply,break-point and next day which is more convenient and save labor.
6.Comply with CE certification.
Technical Parameter
Model | TH-1325M /1212M/2030M |
XY Working Area | 1300*2500mm/1200*1200mm/2000*3000mm |
Z Working Area | 200mm |
Table Size | 1500*3050mm |
Working Mode | Spindle |
Spindle Collect Type | ER 20 |
Cutters Diameter | 3.175mm,4mm,6mm,8mm,10mm,12.7mm |
Voltage | AC 220v 50/60HZ,Single Phase |
AC 380v 50/60HZ,Three Phase | |
Processing Precision | 0.05mm |
Re-Positioning Precision | 0.02mm |
Spindle Speed | 0-24000rpm/min |
Empty Traveling Speed | 0-25000mm/min |
Engraving Speed | 0-12000mm/min |
Work Table Structure | Aluminum Alloy Table |
XY Structure | Ball Screw |
Transmission | X,Y Axis Adopt Rack,Z Axis Is Ball Screw |
Max Moving Speed | 25m/min |
Max, Working speed | 12m/min |
Drive System | Stepper |
Control System | DSP/PCI NC-Studio Control System |
Software Support | Type3,Ucancam,Artcam |
Operation Command | G Code,*.U00,*.mmg,*.plt/HPGL/NC |
Operating System | Computer |
Operation Circumstance | Temperature:0°C~45°C |
Relative humidity:30%~75% | |
Accessories | Water Pump,Cutters,Power Line,USB Line,Fixtures,User Manual,Operating Installation Cds,Artcam Software,Collects, Spanners,Brush,Water Tank,Etc. |
Applicable Industry And Material
1.The furniture industry:cabinet doors,wooden doors,solid wood,panel,door and window furniture.
2.Decoration industry:screen,wave board,large wall hanging,advertising board,marking making.
3.Arts and crafts industry:it can engrave exquisite words and patterns on the man-made stone,wood,bamboo,marble,organic board,double.
Sample
