532nm Compact Green Laser Marking Machine

Green Laser Marker Series is designed to mark highly reflective materials or highly sensitive substrates like silicon wafers with ease and precision. They operate in the visible light spectrum at 532 nm (Green).
The green laser marker is perfect for softer plastics, PCB Boards, IC Chips and for scribing or marking of Solar Cells of various material compositions. We’ve used that experience to develop a green laser that meets the special needs of semiconductor and solar marking applications.
The inherent advantages of the 532 nm wavelength are greater absorption across a wider range of materials, along with mitigated thermal energy allowing it to mark substrates that 1064 nm Near-IR lasers simply cannot. Along with these advantages, the Green Laser Series has very tight spot sizes with the smallest being around 10 um.
Availability:
Quantity:
  • TH-G
  • TH Laser
  • Green Laser

Main Feature

1.Most advanced.New style Green laser marking machine is the 3rd-generation laser marking machine which is manufactured by the most advanced laser technology in the current of the word.

2.Delicate marking.High quality laser beam(near to the limit of diffraction,exporting TEM00 fundamental transverse mode,M2 near to 1,expanding angle of laser beam is only 1/4 of the diode laser marker).Therefore it is very suitable for delicate marking.

3.High Marking Speed.With high repeat frequency of the pulse,power output steadily,energy surge of single pulse is lower than 1%,can achieve high speed marking,and control thedepth and shape of the facula.

4.Comparative advantage.The processing speed is 2-3 times than the  traditional marking machine.

5.Compact design.The size of the machine is very small,potable.Suitable for mobile and fixed working.

6.Ten years life.Ultra-low running cost.The service life of the laser module if more than 100000 hours.The unit power of the whole machine is no more than 0.5kw.

7.High conversion efficiency.more than 30%.

8.Wide range of application.Green laser can mark on all kinds of metal materials and some kinds of nonmetal materials.

9.Easy Operating.Afford the specific marking software based on windows,which is real-time adjust the laser power and pulse frequency.You can edit what you need to mark directly by the specific marking software and the graphic software such as Auto CAD,CORELdraw.photoshop.

10.Free of maintenance.No need adjust laser path.



Technical Parameter

Model

TH-G

Wavelength (nm)

532±1

Work Mode

Q-Switched

Average Output Power (W)

1.5W

3W

Pulse Width(ns)

5ns

Peak Power(KW)

15kW

30KW

Pulse Repetition Rate(KHZ)

20KHZ

20KHZ

Power Stability(RMS,Over 8 Hours)

<1%, <3%

Transverse Mode

TEM00

Beam Divergence,Full Angle(ARC)

<2mrad

Beam Diameter At Aperture(mm)

~6.0mm

Beam Height From Base Plate(mm)

16.5mm

Operating Temp(℃)

10~35(℃)

Voltage

220V/50HZ

Warranty

2 Year

Expected Lifetime(hours)

20000



Applicable Materials

ABS Materials(Appliance Housing,Commodity),PVC,Plastic,Glass,Metal and Alloy(Iron,Copper,Aluminum,Magnesium,Cool System Green Laser Marking Machine For PCB With Qr Code,Bar Code-Buy Green Laser Marking Machine,Mini Laser Marking Machine For PCB,Qr Code Laser Marking Machine Product on Alibaba.com,Zinc etc),Rare metal and Alloy(Gold,Silver,Titanium),etc…



Samples

未标题-1
